E28 Rooftop Air Conditioner

★ ★ ★ ★ ★


Cooling Capacity : 600-2800W/9660BTU

Voltage : DC12V/24V

Refrigerant : R134a

Dimensions : 965.8*808*180

E28 Rooftop Van Air Conditioner System

E28 rooftop van air conditioner can provide a fresh air system for the interior of the van, The roof van air conditioner and the hot air in the car are removed, and then the cold air is sent into the car through the ventilation system, thereby providing a comfortable driving environment for the van.

Electric air conditioners for roof vans operate quietly and efficiently. The compact size of the rooftop air conditioner makes it ideal for use in vans where space is limited. The E28 rooftop air conditioning system is made of durable materials, which can operate normally in severe weather conditions.

Rooftop Air Conditioner Features

★ Very low power consumption, 300W minimum, with ECO mode to save power.

★ The maximum cooling capacity is 2,800w /9,660BTU, which is equivalent to the cooling capacity of 1.5P household air conditioners.
Fully meet the cooling needs of the car.

★ Injection molding, anti-aging, no deformation, the inner insulation layer of the air conditioner is made of environmentally friendly materials
Flame retardant, green travel.

★ With the voltage protection function, when the battery voltage is lower than the minimum starting voltage of the vehicle, the battery voltage will be automatically disconnected.

Model E28
Dimensions 965.8*808*180mm
Air Volume 300m³/h
Cut size/Skylight size 420*340mm or 600*300mm
Weight 35KG
Time of endurance 10 hours (Intelligent frequency control)
Control mode PWM
Power 300-700W
Rated Current 50/60A
Refrigerant R134a---600g
Rated Cooling Capacity 600-2800W/9660BTU
Core component Circulating air volume 300M3/H
Energy efficiency ratio 1.5-2.4W/W
Condenser Parallel flow,Double fin,Dimensions:53*34*2 cm
Evaporator fan Tupe belt type、Dimension:41*13*6 cm
Voltage DC24V/DC12V
